APPLICATION

For water supply from tanks, basins or tubs and from open wells
(large wells) or from 6” wells for residential, civil or agricultural use
and for pressurizing water in general.
Structural specifications
Outer jacket: made entirely from AISI 431 stainless steel, including
delivery casing with 11⁄4“ G threaded outlet.
Impellers and diffusers: hardwearing, thermoplastic resin. Diffusers
fitted with self-adjustable wear rings.
Enbloc pump and motor shaft made entirely from AISI 431 stainless
steel, supported at three points.
Permanently pre-lubricated bearings.
Seals: two mechanical seals: Graphite/alumina oxide seal on motor
side; alumina oxide/silicon carbide seal on pump side. Interposed oil
chamber (FDA-approved, non-toxic oil).
Motor: asynchronous induction motor, with outer jacket in AISI 304
steel, cooled by the pumped liquid. Protection class: IP68
The pump-motor unit is easily dismantled and repaired.
Three-phase versions: 380-400-415 V 50 Hz, protection devices and
electric control panel supplied on request.
Single-phase versions: 220-230 V/230-240 V 50 Hz, complete
electric control panel fitted with protection device and Schuko plug
supplied on request.
H07-RNF type cable supplied as standard: MBS series: L=20 m /
MBS-H series: L=5 m.
Specifications
Qmax: 18 m3/h – Hmax: 113 m
Temperature of pumped liquid: min 0°C – max 40°C.
Maximum quantity of sand allowed in water: 50 g/m3.
Suction of solid bodies: max mm 2.5 (X series: 2 mm).
Minimum level of liquid: 100mm from bottom of suction grid.
Maximum depth of application: up to 70 m below the water level.

USES
Supply of clean water and non-aggressive chemical liquids. OP pumps
are suitable for domestic use, for water automatic distribution by
using small-middle pressuretanks, for gardening, irrigation, water
supply from wells. Furthermore, thanks to the the high head, OP
pumps can be used as pilot pump for pressurization units.

CHARACTERISTIC DATA
16 models subdivided in two series, with power from 0,37 Kw up to
2,2 kW
Qmax: 16 m3/h (50 Hz) / 18 m3/h (60 Hz)
Hmax: 61,5 m (50 Hz) / 58 m (60 Hz)
H (Q=0): 66 m (50 Hz) / 64 m (60 Hz)
Temperature of pumped liquid: min 0°C – max 90°C
Ambient temperature: max 40°C
Max operation pressure (max allowed pressure in consideration of
the sum of max. suction pressure and of the head with null flow rate):
10 bar with temperature of the pumped liquid up to 45°C, 6 bar with
temperature of the pumped liquid from 45°C up to 90°C
